LR5-36HTH-280 Solar Panels For Household Use
GEYA LR5-36HTH-280 Solar Panels For Household Use redefines the value of home photovoltaics with an industry-leading conversion efficiency of 21.5%. It uses monocrystalline silicon technology and precise cell arrangement to achieve an ultra-high power output of 260W~280W (positive tolerance +0~3%) in the same area, meeting the household's all-weather electricity needs. The product is equipped with 3.2mm tempered glass and a lightweight composite frame (only 13kg), with a pressure strength of ≥5400Pa. With an IP68 waterproof connector and anti-PID design, it can operate stably in extreme environments of -40℃~85℃.
LR5-36HTH-280 Solar Panels For Household Use Highlight
1. 21.5% industry-leading efficiency
Adopting advanced monocrystalline silicon technology, it maximizes sunlight conversion rate, reduces roof space occupation, and meets the household's all-weather electricity demand.
2. Ultra-low attenuation, long-term power generation
Power attenuation in the first year is less than 6%, and only 3.5% within 5 years
25-year linear power output guarantee is greater than 80% (leading industry standards)
3. Composite frame + IP68 protection
Lightweight composite frame (13kg) with 3.2mm tempered glass, resistant to wind and snow/corrosion, and adaptable to extreme environments of -40℃~85℃.
4. Flexible adaptation, ready to use
Supports customized cable length, compatible with mainstream inverters, and seamless access to home photovoltaic systems.
Mechanical Parameters
| Cell Orientation | |
| Junction Box | IP68 |
| Output Cable | 4mm², ±1200mm length can be customized |
| Glass | Single glass, 3.2mm coated tempered glass |
| Frame | Composite frame |
| Weight | 13kg |
| Dimension | 1722*767*30mm |
| Packaging | 36 pcs per pallet/216pcs per 20GP/936pcs per 40HQ |
Operating Parameters
| Operational Temperature | -40℃~+85℃ |
| Power Output Tolerance | 0-3% |
| Maximum System Voltage | DC 1000V（IEC/UL） |
| Maximum Serious Fuse Rating | 22A |
| Nominal Operating Cell Temperature | 45±2℃ |
| Protection Class | Class II |
| Fire Rating | UL Type 1 or 2 IEC Class C |
